Hardware Specifications
| Vendor/Brand | Nokia |
| Model | G-010S-B |
| ODM | SourcePhotonics |
| ODM Product Code | |
| Chipset | Lantiq PEB98035 |
| CPU | MIPS 34Kc interAptiv |
| CPU Clock | 400MHz |
| Flash | 16 MB (Macronix MX25L25635FZ2R-10G) |
| RAM | 64 MB (Winbond W9751G6KB-25I) |
| System | OpenWRT |
| HSGMII | Yes |
| Optics | SC/UPC |
| IP address | 192.168.1.10 |
| Web Gui | ✅ user adminadmin, password ALC#FGU |
| SSH | ✅ user ONTUSER, password SUGAR2A041 |
| Telnet | |
| Serial | ✅ on SFP |
| Serial baud | 115200 |
| Serial encoding | 8-N-1 |
| Form Factor | miniONT SFP |
List of partitions
| dev | size | erasesize | name |
|---|---|---|---|
| mtd0 | 00040000 | 00010000 | "uboot" |
| mtd1 | 00080000 | 00010000 | "uboot_env" |
| mtd2 | 00c00000 | 00010000 | "linux" |
| mtd3 | 0013cedb | 00010000 | "kernel" |
| mtd4 | 00ac3125 | 00010000 | "rootfs" |
| mtd5 | 00600000 | 00010000 | "rootfs_data" |
| mtd6 | 00c00000 | 00010000 | "image1" |
| mtd7 | 00200000 | 00010000 | "configfs" |
| mtd8 | 00300000 | 00010000 | "logfs" |
| mtd9 | 00200000 | 00010000 | "extfs" |
| mtd10 | 00010000 | 00010000 | "ri" |
| mtd11 | 00010000 | 00010000 | "sfp" |
| mtd12 | 00010000 | 00010000 | "ribackup" |
| mtd13 | 00010000 | 00010000 | "reserve" |
Serial
The stick has a TTL 3.3v UART console (configured as 115200 8-N-1) that can be accessed from the SFP connector.
| USB TTL(UART) Adapter | SFP 20pins Molex connector |
|---|---|
| 3.3V | pin #15 and #16 |
| TX | pin #2 |
| RX | pin #7 |
| GND | pin #14 and #10 |
Note
Try PIN 10 or other GND PINs if the connection doesn't work by using PIN 14.
Note
Some USB TTL adapters label TX and RX pins the other way around: try to swap them if the connection doesn't work.
General Settings and Useful Commands
Disabling Dying Gasp
sh
uci set gpon.gtc.nDyingGaspEnable='0'; uci commit gpon
